Seamless Half Round Aluminium Gutter Machine For Run Copper Rain Pipe Spout

    Buy cheap Seamless Half Round Aluminium Gutter Machine For Run Copper Rain Pipe Spout from wholesalers

    Buy cheap Seamless Half Round Aluminium Gutter Machine For Run Copper Rain Pipe Spout from wholesalers
    • Buy cheap Seamless Half Round Aluminium Gutter Machine For Run Copper Rain Pipe Spout from wholesalers
    • Buy cheap Seamless Half Round Aluminium Gutter Machine For Run Copper Rain Pipe Spout from wholesalers
    • Buy cheap Seamless Half Round Aluminium Gutter Machine For Run Copper Rain Pipe Spout from wholesalers

    Seamless Half Round Aluminium Gutter Machine For Run Copper Rain Pipe Spout

    Ask Lasest Price
    Brand Name : ST
    Model Number : 400
    Certification : CE ISO9000
    Price : contact us
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 20sets per month
    Delivery Time : 38days after first balance
    • Product Details
    • Company Profile

    Seamless Half Round Aluminium Gutter Machine For Run Copper Rain Pipe Spout


    Seamless Half Round Gutter Roll Forming Machine For Run Copper rain pipe spout aluminium gutter machine


    Details for roll forming machine

    Name

    gutter making machine

    1Suitable raw materialPPGI/PPGL/GI/GL Steel Coils
    2Thickness of coil sheet1-2mm
    3Feeding Coil width400mm
    4Under frame400H-beam
    5Diameter of Soild shaft70mm, high grade 45# steel,with keyway
    6Roller45# steel hard chrome coated 0.05-0.07mm
    7Thickness of middle plate18mm
    8Forming stations16
    9Drive typeBy chain(1.0 inch) link bearing model 6210
    11Power of main motor5.5kw with Cycloidal reducer, Lichao, Shanghai
    12Power of pump station5.5kw, Lichao, Shanghai
    13Forming speedAbout 15-20m/min
    14Hydraulic cuttingControlled by PLC
    15PLCDELTA
    16Material of cutting bladeCr12Mov, quenching 58-62℃

    Main pics:

    Seamless Half Round Aluminium Gutter Machine For Run Copper Rain Pipe Spout


    RFQ:


    Q1. What's your delivery time?
    A1: Depending on the type of machine, duration of 30 days to 60 days from the date of order.

    Q2. Do you have after-sales support?
    A2: Yes, we are happy to give advice and we also have skilled technicians available across the world.We need your machines running in order to keep your business running.


    Q3. Do you sell only standard machines?
    A3: No, most of our machines are built according to customers specifications,using top brand components.

    Q4. What will you do if the machine is broken?
    A4: Our machine's warranty period is 24months,if the broken parts can't repair,we can send the new parts replace the broken parts freely.If it is beyond the warranty period,we can negotiate to solve the problem,and we supply the technical support for the whole life of the equipment,but you need pay the express cost yourself.
