    drywall stud C channel galvanized steel Light Steel Keel Roll Forming Machine

    Ask Lasest Price
    Brand Name : ST
    Model Number : C30
    Certification : ISO CE
    Price : contact me
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 15 sets per month
    Delivery Time : 30 days
    • Product Details
    • Company Profile

    drywall stud C channel galvanized steel Light Steel Keel Roll Forming Machine

    drywall stud C channel galvanized steel Light Steel Keel Roll Forming Machine


    Our Machine Technical Parameter

    No.Itemparameter
    1Machine size7700*800*1300mm
    2Machine weight5000kg
    3Machine power15kw
    4Hydraulic engine3.7kw
    5Roll speed10-15M/Min
    6Roll stations15
    7Roller materialGCr15
    8Effective width30-50mm
    9Feeding width
    10Voltage380V 50Hz 3PH/Customized
    11Material thickness1.5-2.7mm/Customized
    12Control SystemSchneider/Delta/Customized

    Machine Feature:

    1.Precise forming

    2. High-solid forming stand guarantees the goods and uniform high quality of final produced

    3. The operation automatically minimizes the tolerance of cutting length

    4.Machine with Draw knife that can make the last board without manual cutting and clutch,That can control the number plate.

    FAQ

    1. Does one machine can only produce one style panel profile?

    Not exactly.For wider and double layer making machine. It can produce more than 6 kinds of panels.


    2. Do you have after sales support?
    Yes, we are happy to give advice and we also have skilled technicians available across the world.We need

    your machines running in order to keep your business running.


    3. How to visit your company?

    a.Fly to Beijing airport: By high speed train From Beijing Nan to CangZhou Xi (1 hour), then we can pick

    up you.

    b.Fly to Shanghai Airport: By high speed train From Shanghai HongQiao to Cangzhou Xi(4.5 hours), then

    we can pick up you.


    4. What can you do if the machine broken?

    Our machine's warranty period is 12months,if the broken parts can't repair,we can send the new parts replace the broken parts freely,but you need pay the express cost yourself.if after warranty period,we can

    through negotiation for to solve the problems,and we supply the technical support for the whole life of the

    equipment.


    5. Can you be responsible for transport?

    Yes,please tell me the destination port or address.we have rich experience in transport.


    6. You are trade company or factory?
    We are trade company but we also have own factories. Building trade company is just for exporting

    various types of cold roll forming machines.

    7. Why your price is higher than others?
    As we persist on that each factory should put quality at the first place. We spend time and money on

    developing how to make machines much more automatic, accurate and high quality.
