    Fast Speed C Steel Profile Roll Forming Machine Dimension 7000*800*1200mm

    Ask Lasest Price
    Brand Name : ST
    Model Number : 75-150
    Certification : CE ISO
    Price : contact me
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 15 sets per month
    Delivery Time : 30 days
    • Product Details
    • Company Profile

    Fast Speed C Steel Profile Roll Forming Machine Dimension 7000*800*1200mm

    hydraulic drive fast speed C steel profile Purlin Roll Forming Machine


    Equipment Detailed Parameters:

    Raw material
    material specsheet, galvanized steel sheet, aluminum sheet
    thickness of coil sheet0.8-2 mm
    Machine details
    roller materialHigh grade NO. 45 forged steel with 0.05mm hard chrome plating
    shaft materialHigh grade NO. 45 carbon wrought steel
    cutting bladeCr12 mould steel with quenched treatment
    diameter of shaft90 mm
    forming steps12 rows
    productivity8-12 m/min
    hydraulic station power11 KW
    hydraulic pressure10-12MPa
    controlling systemfamous PLC computer control
    material of cutting tableCr 12 mould steel with quenched treatment
    appearance size7500mm*1000mm*1500mm
    hydraulic oil40# hydraulic oil
    Electric tension380V 50 Hz 3 Phase or as your requirements

    Guarantee:

    12 Months guarantee. if some part of the machine is broken. we will supply the best part,but if the damaged parts due to operate error,buyer will pay for the shipping fee.

    After-sale service:

    We sent technician to your country to fix the machine.the buyer shoule bear all the cost includng:visa,roundtrip ticket and suitable accommodation,also buyer should pay the salary 100USD/DAY.

    FAQ

    Q:Are you manufacturer?
    A:Yes,we are manufacturer.We have our own technical team.Welcome to visit us.

    Q:What kind o f payment term you can do?
    A:We are flexible about payment terms,we can also help you on financing,please contact us for details.

    Q:What info you need before you make the proposal?
    A:The pipe diameter and thickness range which you need or the profile drawings,material information,your special requirements.

    Q: What should I do if I just start a new business?
    A:Contact us immediately ,we provide free consultant pre-sales service.Also we can help you to solve the material(steel coil)purchase,worker train,international market price.

    Fast Speed C Steel Profile Roll Forming Machine Dimension 7000*800*1200mmFast Speed C Steel Profile Roll Forming Machine Dimension 7000*800*1200mm
