1. Instruction of the light steel roll forming machine
This machine is one most popular type of roll forming machines. It
makes different shape of color steel roof sheet, which is used for
buildings roof, factory, supermarket ect. For this machine, it suit
coil width is 100mm, thickness range is from 0.3mm to 0.7mm. We
adopt 16mm thick wall board type to make machine frame strong.
Usually it can run with the max speed to 15m/min, PLC with touch
screen operation make the machine simple and easy for usage.
2. General parameters of the production line
| No. | Metal stud roll forming machine |
| 1 | Operating Voltage | 380V,50Hz,3 phases or customized |
| 2 | power | 4kw |
| 3 | productivity | 25m/min |
| 4 | Material type | Strip steel |
| 5 | Roller station | 12 forming steps+4 leveling steps |
| 6 | Thickness to process | 0.3~1.5mm |
| 7 | Main Frame | 300H-beam steel |
| 8 | Roller material | Gcr15 steel,quenched |
| 9 | Side-wall thickness | 20mm |
| 10 | Bearing brand | Harbin |
| 11 | Chain | 1.3 inches |
| 12 | Frequency converter | Equipped |
| Backboard Thickness | 20mm |
| Cutter Standard | GCr12 |
| Roller Standard | Gcr15# |
| Overall Size | About 8500×1000×1400mm |
| Total Weight | About 3.2 T |
| Custom | According to customer's requirements |
1> Free technical support and free accessories supply.
2> Engineer available to service machinery overseas.
3> One year warranty is provided.
4> Long life technical guidance for free.
5> We always offer technical support, quick response, all your
inquire will be replied in 24 hours.
